Hastelloy B3 UNS N10675 Cold Drawn Strip Foil
| Place of Origin | China |
|---|---|
| Brand Name | XUNSHI |
| Certification | ISO9001:2015 |
| Model Number | N10675 |
| Minimum Order Quantity | 50kg |
| Price | Negotiable |
| Packaging Details | Plywood case |
| Delivery Time | 50-60 days |
| Payment Terms | T/T |
| Supply Ability | 500kg per month |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Thickness | 0.1~2.0mm | Width | 30~200mm |
|---|---|---|---|
| Highlight | 2.0mm Cold Drawn Strip,30mm Cold Drawn Strip,Hastelloy Cold Drawn Strip |
||
Product Description
Hastelloy B3 is a nickel-molybdenum alloy with excellent resistance to pitting, corrosion, and stress-corrosion cracking plus, thermal stability superior to that of alloy B2. In addition, this nickel steel alloy has great resistance to knife-line and heat–affected zone attack. Alloy B3 also withstands sulfuric, acetic, formic and phosphoric acids, and other non-oxidizing media. Furthermore, this nickel alloy has excellent resistance to hydrochloric acid at all concentrations and temperatures. Hastelloy B3’s distinguishing feature is its ability to maintain excellent ductility during transient exposures to intermediate temperatures. Such exposures are routinely experienced during heat treatments associated with fabrication.
Limiting Factors of Hastelloy B3
Alloy B-3 has poor corrosion resistance to oxidizing environments, therefore, it is not recommended for use in oxidizing media or in the presence of ferric or cupric salts because they may cause rapid premature corrosion failure. These salts may develop when hydrochloric acid comes in contact with iron and copper. Therefore, if this nickel steel alloy is used in conjunction with iron or copper piping in a system containing hydrochloric acid, the presence of these salts could cause the alloy to fail prematurely.
Advantages of Hastelloy B3
- Maintains excellent ductility during transient exposures to intermediate temperatures
- Excellent resistance to pitting, corrosion and stress-corrosion cracking
- Excellent resistance to knife-line and heat-affected zone attack
- Excellent resistance to acetic, formic and phosphoric acids and other non-oxidizing media
- Resistance to hydrochloric acid at all concentrations and temperatures
- Thermal stability superior to alloy B-2
Chemical composition of Hastelloy B3(N10675)
| Elements | Ni | Mo | Fe | C | Co | Cr | Mn | Si | Ti | W | Al | Cu |
| Weight(%) | 65.0 min | 28.5 | 1.5 | 0.01 max | 3.0 max | 1.5 | 3.0 max | 0.1 max | 0.2 max | 3.0 max | 0.50 max | 0.20 max |
