Iron Cobalt Permanent Magnet Alloy 2J10 Cold Rolled Strip Thickness 0.05-1.0mm Vicalloy

  • Iron Cobalt Permanent Magnet Alloy 2J10 Cold Rolled Strip Thickness 0.05-1.0mm Vicalloy
  • Iron Cobalt Permanent Magnet Alloy 2J10 Cold Rolled Strip Thickness 0.05-1.0mm Vicalloy
  • Iron Cobalt Permanent Magnet Alloy 2J10 Cold Rolled Strip Thickness 0.05-1.0mm Vicalloy
Place of Origin China
Brand Name XUNSHI
Certification ISO9001
Model Number 2J10
Minimum Order Quantity 20 kgs
Price Negotiable
Packaging Details Plywood case
Delivery Time 30 days
Payment Terms T/T
Supply Ability 500 kgs per week

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Density 8.1 G/cm3 Melting Range 1530-1600°C
Cuire Piont 860°C Resistance Rate 0.71 μΩ·m
Forms Of Supply Bar, Wire, Strip Product Name Permanent Magnet Alloy
Highlight

Cold Drawn Wire Cobalt Iron Alloy

,

Strip Permanent Magnet Alloy

,

Thickness 1.0mm Permanent Magnet Alloy
Leave a Message
Product Description

Iron Cobalt Permanent Magnet Alloy 2J10 Cold Rolled Strip Thickness 0.05-1.0mm Vicalloy



2J10 can be precipitation hardened. It has good plasticity, and could be cold processed by forging, rolling and drawing and cutting. Usually, 2J10 is applied to motor equipment, such as hysteresis motor, hysteresis brake, etc. Fe-Co-V hysteresis alloys have good plasticity before tempering. After cold rolling (or drawing) with 90% strain, excellent hysteresis properties and strong magnetic anisotropy can be obtained, i.e. longitudinal magnetic properties are better than transverse ones. Therefore, if the wire can be used as the rotor of hysteresis motor in the manufacturing process, its performance is better, and it has more development prospects.



Chemical compositions

Elements Weight(%)
C ≤0.12
P ≤0.25
S ≤0.02
Si ≤0.70
Mn ≤0.70
Co 51.0~53.0
V 9.5~10.5
Ni ≤0.70
Fe Rem



2J10 Magnetic performance

Hμ(kA/m)

(Hμ/Oe)

Bμ/T

(Bμ/Gs)

 Pμ(104J/m3) Kμ
14.4~18.4(180~230) 0.9~1.2(9000~12000) 3.0 0.58



Applications

High efficiency hysteresis motor rotor and hysteresis brake.

Good corrosion resistance, and not rust in the atmosphere.



Density

8.1g/cm3



Available forms

Round bar,Cold drawn wire,Cold rolled strip,Forging

2J10 strip is delivered without heat treatment at cold rolled state and can be supplied specifications range as below

Strip thickness: 0.05-1.0mm

Strip Width 5-200mm

Round bar Specification range: Φ5-200mm

Wire Specification range: Φ0.1～6.0mm



Iron Cobalt Permanent Magnet Alloy 2J10 Cold Rolled Strip Thickness 0.05-1.0mm Vicalloy 0Iron Cobalt Permanent Magnet Alloy 2J10 Cold Rolled Strip Thickness 0.05-1.0mm Vicalloy 1Iron Cobalt Permanent Magnet Alloy 2J10 Cold Rolled Strip Thickness 0.05-1.0mm Vicalloy 2
